What's the Diagnosis? By Joseph Cesarine

Answer: Avulsion fracture of the fibular styloid process, compatible with an arcuate sign.

 Fibular Styloid Fracture/Arcuate Sign

  • Mechanism is direct trauma to the anteromedial knee while in extension or sudden hyperextension; also seen in knee dislocations.
  • Avulsion fracture at the proximal fibula at the insertion site of the arcuate ligament; 90% of fractures have disruption of the lateral collateral ligament
  • Injury to other structures of the posterolateral ligamentous complex is also common.
  • This injury is highly suspicious of an unstable knee joint and needs emergent orthopedic evaluation.
  • Due to anatomic location of fracture, can also involve injury to peroneal nerve.
